INSERT FOR MILLING BRAND SANDVIK TPKN 22 04 PD R 530

INSERT FOR MILLING BRAND SANDVIK TPKN 22 04 PD R 530

Workpiece material(s)(TMC1ISO): PMNH
Operation type (CTPT): pre-machining with demand on surface
Insert mounting style code (metric)(IFS): Without fixing hole
Insert size and shape (CUTINT_SIZESHAPE): TP2204PD
Cutting edge count(CEDC): 3
Inscribed circle diameter(IC): 12.7 mm
Insert shape code(SC): Triangular
Cutting edge effective length(LE): 18 mm
Depth of cut maximum (APMX): 18 mm
Corner chamfer(KCH): 45°
Corner chamfer width(CHW): 0.4 mm
Wiper edge length(BS): 1.4 mm
Major cutting edge angle(KRINS): 90 °
Insert rake angle(GAN): 0 °
Grade (GRADE): 530
Substrate(SUBSTRATE): HT
Insert thickness(S): 4.7625 mm

Packaging: 1 Box contains 10 pcs

*Authorized Sandvik Coromant Distributor
