xTool manufacturers, mechanical engineering, the aircraft industry and reconditioners can look forward to even more versatility and performance. With BALINIT® LATUMA, developed on the basis of the BALINIT® coatings FUTURA NANO and X.CEED, it offers you decisive advantages. Not only is the machining and use of a wide variety of challenging materials even more productive now, the process reliability under difficult working conditions is also increased at the same time.
Employ this coating solution for indexable inserts and shank-type tools – take your metal processing business to new levels of success with BALINIT® LATUMA.
- For challenging conditions
- Highly resistant to crater wear and oxidation
- Ideal for wet and dry machining
| BALINIT® LATUMA | |
|---|---|
| Coating material | AlTiN-based |
| Coating technology | Arc |
| Coating color | grey |
| Coating hardness HIT [GPa]* | 35 +/-3 |
| Intrinsic stress [GPa]*** | -3 +/-1 |
| Max. service temp. [°C]**** | 1000 |
| Process temperature [°C] | < 500 |
| General remark | All given data are approximate values, they depend on application, environment and test condition. |
| Coating hardness HIT [GPa] | Measured by nano indentation according to ISO 14577. For multilayers the hardness of the different layers varies. Hardness can be adapted to the application. |
| Intrinsic stress [GPa] | Measured by XRD and/or bending method (Stoney equation). The calculated thermal stress has been substracted. |
| Max. service temp. [°C] | These are approximate values out of the field. Due to thermodynamic laws there is a dependency of pressure in application. |
Passion For Surface Solutions.
*For further inquiries or quotation, please contact us.
